Single wall Heavy duty bit

Variations available

The combination of dome buttons, wear protection, water slots, inner cutting buttons, and overcut makes this bit highly effective in tougher drilling conditions.


Description

Note: While this bit is capable of drilling through tough soils, switching to a dual wall core barrel bit is recommended for extended drilling in rock formations to improve efficiency and prolong bit lifespan.

Important: the CB4 Single wall heavy duty bit can only be used in combination with the EM7 casing.

Product variants

  • D017316
    CB4 Single wall heavy duty bit
    OD 132 mm / ID 95 mm
    OD 5.20 in / ID 3.74 in
  • D0035285
    CB4 1/2 Single wall heavy duty bit
    OD 147 mm / ID 111 mm
    OD 5.79 in / ID 4.37 in

Specifications

Single wall Heavy duty bit
Applications Medium or compact formations, stiff clay, and medium rock.
Type of button Dome buttons
Usage of overcut yes
Water slots yes
Wear protection buttons yes
Inner cutting buttons yes
Water discharge Yes, between the sample and the bit due to the inner cutting buttons.
General This bit can be used in combination with a core catcher.
